Milling fixture for fabricated plenum project

This is the final milling fixture Tony made for one of the plenums he is working on

Fixture is made with steps in it so it can be used for multiple machining operations



IMG 0438

Milling multiple parts at one time

Our customer made the parts.  T&M Precision was to mill the heads on the rods smooth

To save time and money, Tony made this fixture to machine 50 parts at the same time



welding fixture for welding small flange on plenum

IMG 0435This is one of the welding fixtures Tony made for one of the plenums he is working on.

He had to make several fixtures to make these parts.  This is the one he made to weld the small flange on



second view of welding fixture for small flange

different view of welding fixture for welding small flange on plenum



IMG 0437

one welding fixture for plenum

This is one of several fixtures Tony made for welding one of the plenum projects he is working on


ws1IMG 5415




ws2IMG 5414
